Most home networks are flat: every device — your laptop, your phone, your smart fridge, your IP camera — lives on the same subnet. If any one of them is compromised, the attacker can pivot to everything else. This post documents how I redesigned mine from scratch.

Why segment at all?

A flat /24 gives you 254 usable addresses and zero trust boundaries. The moment an IoT device with a backdoor hits your network, it can talk freely to your NAS, your workstation, your Raspberry Pis. Segmentation with VLANs enforces isolation at layer 2 — no routing between zones unless you explicitly allow it.

Hardware I used

• pfSense (running on a Protectli VP2420 mini-PC) as the router/firewall
• TP-Link TL-SG108E managed switch — 8-port, supports 802.1Q VLANs, costs ~$30
• Ubiquiti UAP-AC-Lite access point (supports multiple SSIDs per VLAN)

VLAN layout

pfSense firewall rules

The key rule set: IOT can never initiate connections to TRUSTED or LAB. Only return traffic is allowed (stateful firewall handles this automatically). LAB can reach the internet but not TRUSTED.

# IOT outbound — internet only
pass out on VLAN30 all
block in on VLAN30 destination <trusted_net>
block in on VLAN30 destination <lab_net>

Switch configuration

On the TL-SG108E: set each port as an access port for a single VLAN (untagged) or a trunk port carrying multiple VLANs (tagged) toward the pfSense uplink and the AP.

Port 1 → pfSense (tagged: VLAN10, 20, 30, 99)
Port 2 → AP      (tagged: VLAN10, 30)
Port 3 → NAS     (untagged: VLAN20)
Port 4-6 → Lab servers (untagged: VLAN20)

What I learned

• Start with the firewall rules before plugging anything in. It is much easier to open holes selectively than to close them retroactively.
• VLAN 1 is the default VLAN on most switches — never put production traffic on it. Use it for nothing, or disable it.
• DNS matters. Run a separate Pi-hole per VLAN or use pfSense’s DNS resolver with VLAN-aware overrides so IoT devices can not query your internal hostnames.

The result: a network where my IP cameras literally cannot reach my laptop, even if I try.

A Raspberry Pi 4 (4 GB) costs $55. For that price you get a always-on Linux box that can block ads network-wide, collect metrics from every device on your network, and serve a Grafana dashboard — all simultaneously.

What we are building

1. Pi-hole — DNS-level ad and tracker blocker for the entire network
2. Prometheus — time-series metrics collector
3. Grafana — dashboard to visualise everything
4. pihole-exporter — bridge between Pi-hole stats and Prometheus

Install Pi-hole

curl -sSL https://install.pi-hole.net | bash

Set a static IP on the Pi first. Then point your router’s DHCP to hand out the Pi’s IP as the DNS server for all clients.

# /etc/dhcpcd.conf
interface eth0
static ip_address=10.0.20.10/24
static routers=10.0.20.1
static domain_name_servers=127.0.0.1

Install Prometheus

sudo apt install prometheus

Default config scrapes itself every 15s. We will add pihole-exporter as a target.

Install pihole-exporter

wget https://github.com/eko/pihole-exporter/releases/latest/download/pihole_exporter-linux-arm
chmod +x pihole_exporter-linux-arm
./pihole_exporter-linux-arm -pihole_hostname 127.0.0.1

Add to Prometheus scrape config:

scrape_configs:
  - job_name: pihole
    static_configs:
      - targets: ['localhost:9617']

Install Grafana

sudo apt install grafana
sudo systemctl enable --now grafana-server

Import dashboard ID 10176 (Pi-hole Exporter) from grafana.com — it gives you blocked queries %, top blocked domains, query rate, and client breakdown out of the box.

Metrics worth watching

• Blocked % — healthy range is 15–30%. Much lower means blocklists are stale. Much higher might mean false positives.
• Query rate by client — spot anomalous devices making thousands of queries per minute (IoT malware signature).
• Top permitted domains — tells you what your devices actually phone home to.

Performance on Pi 4

After 30 days of continuous operation: CPU never exceeded 12%, RAM usage settled at ~380 MB. The SD card is the bottleneck — use a good A2-rated card or boot from USB SSD.

Every time I expose a Linux machine to the internet I run through the same checklist. These are not theoretical controls — they are the minimum I apply before any service goes live.

1. Disable root login and password auth

# /etc/ssh/sshd_config
PermitRootLogin no
PasswordAuthentication no
PubkeyAuthentication yes

Generate a key pair locally, copy the public key, then restart sshd:

ssh-keygen -t ed25519 -C "homelab"
ssh-copy-id -i ~/.ssh/id_ed25519.pub user@server
sudo systemctl restart sshd

2. UFW — allow only what you need

sudo ufw default deny incoming
sudo ufw default allow outgoing
sudo ufw allow 22/tcp    # SSH — change to your port
sudo ufw enable

Never open port ranges. Never use ufw allow from any. Be explicit.

3. fail2ban

Blocks IPs after repeated failed auth attempts:

sudo apt install fail2ban

# /etc/fail2ban/jail.local
[sshd]
enabled  = true
port     = 22
maxretry = 3
bantime  = 1h
findtime = 10m

sudo systemctl enable --now fail2ban

4. Unattended security upgrades

sudo apt install unattended-upgrades
sudo dpkg-reconfigure --priority=low unattended-upgrades

This auto-applies security patches daily without touching non-security packages.

5. Audit with Lynis

Lynis is an open-source security auditing tool that scores your system against CIS benchmarks:

sudo apt install lynis
sudo lynis audit system

Aim for a hardening index above 70. Common quick wins: disable unused kernel modules, restrict /proc mount options, enable auditd.

6. Change the SSH port

Not real security, but it eliminates 99% of automated scan noise in your logs:

# /etc/ssh/sshd_config
Port 2222

Update UFW to allow the new port before restarting sshd — or you will lock yourself out.

What I skip (and why)

• SELinux/AppArmor profiles for every service — useful but high maintenance. I use AppArmor only for internet-facing services.
• Port knocking — adds friction without meaningful security if you already have key-only auth + fail2ban.

Security is a process, not a checklist. Run Lynis monthly and re-evaluate after any major config change.
